Two-component silicone systems for photovoltaic electronics

PV optimisers, microinverters and safety switches contain compact power electronics and circuit boards that have to run reliably on a continuous basis. The WEVOSIL 2210x series of silicone potting compounds, specially developed by Wevo for modern electronics, combines effective heat dissipation with high insulation properties and heat resistance. Their self-adhesive properties support reliable heat dissipation and reduce thermal stress on sensitive components. This is a significant factor in the cost-effective operation of solar PV systems.

These reactive RTV silicones have an extremely low Shore hardness and viscosity. As a result, they help to reduce tension, preventing crack formation and delamination on housings, circuit boards and solder joints – even when subject to major temperature changes or mechanical stresses such as vibration. Also, the flame retardant silicone potting compounds fulfil fire protection requirements according to UL 94 V-0 and can therefore be used in installations near and on buildings or in large industrial systems.

RELIABLE SEALING FOR JUNCTION BOXES AND CONNECTORS

In PV junction boxes, DC and AC connectors as well as cable systems, silicone potting compounds from Wevo ensure reliable sealing against moisture and UV radiation. Integrated bypass diodes – which are vital for protecting shaded areas of modules – also benefit from the use of these two-component systems.

In addition to their hydrophobic properties and high dielectric strength, WEVOSIL products contribute to the longevity of these sensitive components through their ultra-soft, gel-like consistency. Even under extreme temperature changes, harsh weather conditions and high mechanical stresses, they provide reliable protection – including for components with complex geometries.

Low-viscosity, free-flowing two-component silicone potting compounds can be processed efficiently in automated potting processes using standard mixing and dispensing systems. They have already proven themselves in real-world applications – making WEVOSIL 2210x the ideal choice for the series production of high-performance components in modern solar PV systems.
