WEVOPUR



The filling characteristics of the resin components increase thermal conductivity, enabling designers to achieve optimal thermal management. WEVOPUR is also mechanically versatile with properties ranging from gel-like to elastomeric and impact-resistant to high dimensional stability. Clear, UV-stable systems are also available for transparent applications.

Main product features

  • Broad hardness range: Shore 00 to D 90
  • Adjustable flow properties
  • Filled and unfilled systems
  • Good temperature cycle behaviour
  • Clear, UV-resistant systems
  • Low dielectric constant
  • Self-extinguishing systems in accordance with UL 94 V-0
  • Good adhesion not only on conventional thermoplastics, but also on high-performance plastics such as LCP, BMC, etc.
  • Operating temperature range: -60 °C to +165 °C
  • Pot life adjustable from 1 to 90 minutes
  • Thermal conductivity up to 2.0 W/m·K

Overview of representative polyurethane products

* File-No. E108835
WEVOPUR 552 FL PD 4 403 FL/33
WEVONAT 300 385 300 RE
Operating temperature [°C] -40 bis +130 -60 bis +120 -50 to +165
Flammability V-0, 1.5 mm* HB V-0, 1.6 mm*
Shore hardness A/D -- / 60–70 60–75 / -- -- / 40–50
Glass transition temperature [°C] 15 -60 -6
Dielectric constant ε at 23 °C, 50 Hz 5.6 3.1 5.7

WEVOPUR offers versatile and adjustable reactivity and flowability.
